Cooke Anamorphic Prime Lenses

Harness all of the anamorphic lens characteristics demanded by filmmakers today with the Cooke Look and oval bokeh. Achieve exceptional shape, depth and form with unparalleled optical and mechanical performance.

High performance

Images beautifully rendered for film, with aberrations like astigmatism and longitudinal colour corrected exceptionally well.

Convenient

Specially manufactured with a coating that allows you to kick flares, bokeh and other aberrations into new visual territory.

Practical

Ten focal lengths, all colour matched to our S4/i, 5/i and miniS4/i lenses.

Intelligent

Equipped with the next generation of /i Technology to automatically record key lens data for every frame shot.

See the Range

Anamorphic Showreel

Watch our showreel showcasing the latest to be shot on the Cooke Anamorphic/i.

Test Footage

Anamorphic/i test film

Test Footage

Anamorphic/i test film

Test Footage

Anamorphic/i test film

Test Footage

Anamorphic/i test film

Anamorphic_i test film_1
Anamorphic_i test film_3
Screenshot 2021-05-05 at 11.17.19
Anamorphic_i test film_4

Technology

Cooke’s /i Technology automatically records key lens data for each frame shot, from lens setting and focusing distance to aperture, depth-of-field and beyond. Streamlining production and post, it equips cinematographers with the information to eliminate guesswork and facilitate greater creative freedom.pth-of-field. Equipping cinematographers with essential information, it streamlines production and post processes while eliminating the need for guesswork.

01
02@2x
03@2x

Shot on Cooke Anamorphic

VIEW ALL

Halloween 2018

  • Credits
    • Halloween 2018
    • Director of Photography: Michael Simmonds

Handcrafted Innovation

Classic polishing techniques are used to achieve the highest level of precision.

Screenshot 2021-01-14 at 13.25.46

We collect more measurements than ever before to ensure superior quality.

Screenshot 2021-01-14 at 13.25.46

Minerals are evaporated at a high temperature in a vacuum to produce a thin film on the glass.

Screenshot 2021-01-14 at 13.25.46

Edging is carried out to ensure that glass diameters are perfectly round.

Screenshot 2021-01-14 at 13.25.46

Lenses are carefully tested, checked, modified, cleaned and rechecked.

Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46
Screenshot 2021-01-14 at 13.25.46

All Features

Optical Design

The Anamorphic/i series comprises of 10 Anamorphic Prime Lenses. These Lenses are optimised for film and digital film cameras reducing lateral colour aberration and providing an organic bokeh look. Anamorphic/i lenses are designed to provide maximum performance at full aperture with superior control of flare, distortion and spherical aberration. The optics feature a 2x squeeze factor for super35 formats in 2.4:1 aspect ratio.

Aperture

All Anamorphic/i lenses cover Super 35mm formats

Focus Movement

Ergonomically designed to have smooth and accurate travel – whilst utilising precision mechanics to provide a consistent feel in operation through the entire focus movement.

/I Technology

The Cooke /I Technology ecosystem provides critical lens metadata such as focus and Iris position. Suitable for the most modern VFX applications such as Virtual Production shooting.

Standardised

All Anamorphic/i series Lenses have standardised 0.8 MOD focus and Iris drive gears. Most lenses in the series also feature a fixed common front diameter of 110mmm (The 25mm, 65MACRO, 300mm Lenses feature a 136mm front diameter)

Weight/Size Ratio

Optimised for the series

Colour Balance

All Anamorphic/i lenses are colour balanced and colour matched – ensuring consistency across the series

Iris

The Anamorphic/i series of prime lenses feature an eleven-leaf linear module iris assembly. Providing an aperture range of T2.3-T22 (65MACRO T2.6-T22)

Focus Scales

All lenses have factory calibrated focus scales with clearly identifiable distance marks

Camera Mounts

Precision PL Mount with /i Technology Electrical Contacts

External Finish

Durable and Hard wearing surface finish to meet the needs of the most demanding environmental conditions

Reliability and Service

All Anamorphic/i series lenses are designed for full performance and reliability with a minimum of downtime

Specifications

T-Stop Range
Angular Rotation of Iris Scale
Min. Marked Object Distance
Close Focus from Lens Front
Angular Rotation to MOD Endstop
Max. Diagonal Angle of View for Super 35 Format
Length from Front of Lens to Lens Mount
Max Front Diameter
Total Weight
DOWNLOAD SPECIFICATIONS download-icon
25mm32mm40mm50mm65mm MACRO75mm100mm135mm180mm300mm
T2.3-T22T2.3-T22T2.3-T22T2.3-T22T2.6-T22T2.3-T22T2.3-T22T2.3-T22T2.8-T22T3.5-T22
90°90°90°90°90°90°90°90°90°90°
840 mm 33 in840 mm 33 in840 mm 33 in840 mm 33 in450 mm 18 in1000 mm 39 in1100 mm 44 in1400 mm 56 in2000 mm 78 in3000 mm 120 in
550 mm 22 in550 mm 22 in550 mm 22 in550 mm 22 in140 mm 5.5 in800 mm 31 in900 mm 35 in1200 mm 47 in1650 mm 64 in2580 mm 101.5 in
300°300°300°300°300°300°300°300°300°300°
96.9°77.5°62.8°50.7°36.9°34.1°25.7°19.1°13.9°8.5°
203 mm 8 in195 mm 7.68 in195 mm 7.68 in195 mm 7.68 in258 mm 10.1 in195 mm 7.68 in195 mm 7.68 in195 mm 7.68 in296 mm 11.65 in378 mm 14.88 in
136 mm 5.35 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in136 mm 5.35 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in110 mm 4.33 in136 mm 5.35 in
4.2 kg 9.26 lbs3.2 kg 7.1 lbs3.4 kg 7.5 lbs3.6 kg 7.9 lbs5.2 kg 11.5 lbs3.2 kg 7.1 lbs3.4 kg 7.5 lbs4.2 kg 9.3 lbs5.8 kg 12.8 lbs9.4 kg 20.7 lbs
